• Micro finished brass seat to ensure no reduced pressure creep
• Reinforced diaphragm for repeated accuracy
• Minimal pressure drop due to efficient aspiration
• Three position non-rising adjustment knob; push to lock, pull to adjust, detach to make tamper resistant
• Relieving style standard
• Easily panel mounted
• Tamper-proof cap included
• In-Line or modular installation
• High scfm flow due to efficient aspiration


SPECIFICATIONS

Body - Black E coated aluminum
Bonnet - Glass filled nylon
Seals - Buna N Elastomer Standard
Seat - Brass
Supply Pressure - Max pressure 250 psig
Operating Pressure Range - 5-125 psig
Operating Tempeature Range - 40°-120° F
Gauge Ports - 1/4" Full Flow

DIMENSIONS: 1/4" inlet and outlet, 5.5" tall, 2.75" wide

WEIGHT: 2 LBS.
