Features

• High grade filter element
• Element construction of injection molded thermoplastic
• Integrated gasket seal
• Positive seal between housing hemispheres
• New seal with each element
• Minimizes parts
• Optimal surface area per given size
• Pleated media for high dirt holding capacity
• Element Part Number
• Polyester Paper
• Dimensions - inches
• O.D. H.T.
• Surface Area ft2
• Element
• SCFM
• Rating
• 03 02 1 1/2 1 0.1 3
• 05 04 2 1/4 1 0.2 8
• 07 06 3 1 3/8 0.58 12
• 11 10 4 1 3/8 1.1 35
• 17* 16 8 3 1/4 8 250
• See Element Technical Data for maintenance guidelines. Contact factory for options.
• Polyester Media Benefits/Specs
• Less maintenance due to longer durability
• Moisture resistant
• Handles hot air and oil mist from unload cycle of
• reciprocating/piston compressor
• Washable with lukewarm water and mild detergent
• (replacing element is recommended)
• Paper Media Benefits/Specs
• Heavy duty industrial strength paper
• Cost effective
• Gently blow out media (replacing element is recommended)
• *Minimum order quantity applies.
• OD
• HT
